DEll PowerEdge R760XD2 2U Computer Server Intel Xeon 6426Y 32GB 1400W PSU DDR5 2U 2-socket R760XD2 Network Rack Server

Product Description

Product Parameters
Server Model Dell EMC PowerEdge R760XD2
Features Technical Specifications
Processor Up to two 4th Generation Intel Xeon Scalable processors with up to 56 cores per processor and optional Intel QuickAssist Technology
RAM Up to 16 DDR5 RDIMMs (up to 1TB supported), NVDIMM No, DIMM Speed: up to 4800 MT/s
Storage controllers
  • Internal Controllers: PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i
  • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB
  • External HBA (non-RAID): HBA355e
  • Software RAID: S160
Drive Bays
  • Front bays:
  • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 240 TB
  • Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB
  • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB
  • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.64 TB
  • Rear bays:
  • Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
  • Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
Power supplies
  • 2800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant
  • 2400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant
  • 1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant
  • 1400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant
  • 1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant
  • 1100 W LVDC -48 — -60 VDC, hot swap redundant
  • 800 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant
  • 700 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant
Size
  • Height – 86.8 mm (3.41 inches)
  • Width – 482 mm (18.97 inches)
  • Depth – 772.13 mm (30.39 inches) with bezel, 758.29 mm (29.85 inches) without bezel
Fans
  • Standard (STD) fans / High performance Silver (HPR) fans / High performance Gold (VHP) fans
  • Up to 6 hot plug fans
Outline specification 2U rack server
Embedded management
  • iDRAC9
  • iDRAC Direct
  • iDRAC RESTful API with Redfish
  • iDRAC Service Module
  • Quick Sync 2 wireless module
Embedded NIC 2 x 1 GbE LOM
GPU options Up to 2 x 350 W DW and 6 x 75 W SW
Port
  • Front Ports: 1 x iDRAC Direct (Micro-AB USB) port, 1 x USB 2.0, 1 x VGA
  • Rear Ports: 1 x Dedicated iDRAC Ethernet port, 1 x USB 2.0, 1 x USB 3.0, 1 x VGA, 1 x Serial (optional), 1 x VGA (optional for Direct Liquid Cooling configuration)
PCIe
  • Slot 1: 1 x8 Gen5 or 1 x8/1 x16 Gen4 Full height, Half length or 1 x16 Gen4 Full height, Full length
  • Slot 2: 1 x8/1 x16 Gen5 or 1 x8 Gen4 Full height, Half length or 1 x16 Gen5 Full height, Full length
  • Slot 3: 1 x16 Gen4 Low profile, Half length
  • Slot 4: 1 x8 Gen4 Full height, Half length
  • Slot 5: 1 x8/1 x16 Gen4 Full height, Half length or 1 x16 Gen4 Full height, Full length
  • Slot 6: 1 x16 Gen4 Low profile, Half length
  • Slot 7: 1 x8/1 x16 Gen5 or 1 x8 Gen4 Full height, Half length
  • Slot 7 SNAPI: 1 x16 Gen5 Full height, Half length
  • Slot 8: 1 x8 Gen5 or 1 x8 Gen4 Full height, Half length
Operating system and hypervisor
  • Canonical Ubuntu Server LTS
  • Microsoft Windows Server with Hyper-V
  • Red Hat Enterprise Linux
  • SUSE Linux Enterprise Server
  • VMware ESXi
  • For specifications and interoperability details, see the OS support documentation.
Warranty 3 years
Products Description
Dell PowerEdge R760xd2
Dell PowerEdge R760xd2

Meet Your Growing Unstructured Data Needs With Object Storage Technology Designed to Be Easily Configurable, Serviceable, and Scalable. This 2U, 2 socket Server is Ideal for File and Object Storage, Video Capture/Retrieval, and Content Delivery Networks.

Product Display
Product Display 1
Product Display 2
Product Display 3
Product Display 4
Product Display 5
Product Display 6
Product Display 7
Application Scenario
Application Scenario
Profile
Infrastructure

As a leading integrated IT solutions provider, we combine cutting edge in house manufacturing, dedicated R&D facilities, and a robust global distribution network to deliver comprehensive end to end infrastructure services. With a team of over 300 highly skilled professionals, including more than 150 certified engineers holding top tier certifications, we bring 15 years of proven expertise in designing, deploying, and maintaining mission-critical IT environments for enterprises worldwide. Our vertically integrated approach ensures seamless quality control from component sourcing to final implementation. As authorized partners for Huawei, xFusion, Dell, HPE, and Lenovo, we provide:

  • Computing servers
  • Network storage
  • Network switches
  • CPU, RAM, HARD DRIVES, and other accessories
Exhibition
Exhibition
Packing & Delivery
Packing Process 1
Packing Process 2

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

FAQ
Q1: When can I get the quotation?
We usually quote within 24 hours after receiving your inquiry. If your request is urgent, please specify when submitting your inquiry, and we will prioritize it accordingly.
Q2: What warranty is provided with the equipment?
We provide a comprehensive 3-year replacement warranty on complete machine products. We maintain a robust and integrated supply chain system to resolve any post-sales technical issues quickly and efficiently.
Q3: Are the memory modules and other accessories original?
Yes, all memory modules utilize original brand chips. Every single memory module and hardware component undergoes strict technical testing before delivery.
Q4: What payment options do you support?
We support a range of secure payment methods, including Alipay, credit cards, bank wire transfers (T/T), and other transaction channels to process your order securely.
Q5: What is the Minimum Order Quantity (MOQ) for orders?
Minimum order quantities vary depending on the product lines. Please share your exact requirements, and we will do our best to meet your procurement needs. Small or sample orders are welcome.
Q6: Why is there a price gap for items that appear visually identical?
Although different equipment configurations may look identical on the exterior, internal component specifications and performance grades can vary significantly. These differences lead to variations in hardware configurations and pricing, ensuring matches for different user requirements.
