The FusionServer 2288H V5 is a 2U 2-socket rack server with flexible configurations, which can be widely used for cloud computing, virtualization, database, and big data workloads.
The 2288H V5 can be configured with 2-socket Intel® Xeon® Scalable processors, 24 ports of DDR4 memory, 10 PCIe expansion slots, and supports large-capacity local storage resources. It integrates patented technologies such as DEMT, intelligent power consumption management, FDM intelligent fault management, and optional FusionDirector full lifecycle management software, which can effectively reduce operations cost and improve return on investment.
| Server Model | FusionServer 2288H V5 |
| Form Factor | 2U, 2-socket rack server |
| Processors | 1/2 x 1st Gen Intel® Xeon® Scalable processors 3100/4100/5100/6100/8100 series, up to 205W 1/2 x 2nd Gen Intel® Xeon® Scalable processors 3200/4200/5200/6200/8200 series, up to 205W |
| Local Storage | Supports hot swapping: • 8/20/24/25/31 x 2.5-inch SAS/SATA/SSD • 12/16/20 x 3.5-inch SAS/SATA • 4/8/12/24/28 NVMe SSD • Dual M.2 SSDs |
| RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, 60; Cache supercapacitor protection; RAID level migration, disk roaming, self-diagnosis. |
| Network | On-board: 2 x 10GE ports + 2 x GE interfaces Flexible card options: GE, 10GE, 25GE, or 56G FDR IB. |
| PCIe Expansion | Up to 10 PCIe 3.0 slots, including dedicated RAID and LOM slots. |
| Fan Modules | 4 hot-swappable fan modules (N+1 redundancy). |
| Dimensions | 3.5-inch chassis: 86.1mm x 447mm x 748mm 2.5-inch chassis: 86.1mm x 447mm x 708mm |
| Power Supply | 2 hot-swappable PSUs (1+1 redundancy): 550W/900W/1500W Platinum; 1500W HVDC; 1200W DC. |
As a leading integrated IT solutions provider, we combine cutting edge in-house manufacturing, dedicated R&D facilities, and a robust global distribution network to deliver comprehensive end-to-end infrastructure services. With a team of over 300 highly skilled professionals, including more than 150 certified engineers, we bring 15 years of proven expertise in designing, deploying, and maintaining mission-critical IT environments for enterprises worldwide.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
